How do you use an aerosol conformal coating? (CTSR-12)

Shake well. SURFACE MUST BE CLEAN & MOISTURE FREE. Areas not requiring coating should be masked. Coating:  Spray top to bottom, allowing coating to flow around components. Rotate board 90˚ and repeat process 2 or more times.  If nozzle clogs, clean with solvent or use new nozzle. Cure:  A 1.0 mil coating will be tack-free in 15 minutes.  Full cure requires 24 hours @77˚F/25˚C. Heat Cure: 8 hours @170˚F/77˚C. An open vessel of water placed in the drying chamber will facilitate curing. UV detectable for QC inspection. An open vessel of water placed in the drying chamber will facilitate curing. UV detectable for QC inspection. Removal: Coating may be removed by soaking in Electro-Wash® Two Step. Use CircuitWorks® Conformal Coating Remover Pen for spot removal. After the new component is installed, areas should be cleaned and re-coated.
